C5 mk1 wheel alignment

This is the Forum for all your Citroen Technical Questions, Problems or Advice.

Moderator: RichardW

cornesoutafrica
Posts: 161
Joined: 05 Nov 2018, 19:20
x 9

C5 mk1 wheel alignment

Post by cornesoutafrica »

Hi everyone

After replacing my inner tierod end the car had to get wheelalignment. I don’t drive her muck so took her for one today.

Apparently the caster and camber is out and non adjustable, is that true? He gave me a printout. Toe could be adjusted. But that was it.

I attach the printout. ES9 I believe is to do with the engine code?

What do you guys suggest to rectify the caster and camber?
Attachments
After adjustment
After adjustment
Before adjustment
Before adjustment

User avatar
GiveMeABreak
Forum Admin Team
Posts: 20345
Joined: 15 Sep 2015, 19:38
x 2002

Re: C5 mk1 wheel alignment

Post by GiveMeABreak »

Hi Corne, that is also my understanding - here is the official data and settings:

C5 Toe.PNG
C5 Toe.PNG (26.89 KiB) Viewed 345 times
N.B.: Front of the vehicle (following the arrow ).
B lower or equal to C : Positive figure (+) (toe-in).
B greater than or equal to C : Negative figure (-) ( opening).

Geometry of the front suspension
Checking values
CastorNon-adjustable3° 03' ± 30'
TrackingAdjustable-0°13’ ± 0°13’
King pin inclinationNon-adjustable12°56’ ± 30’
CamberNon-adjustable0° ± 30'

Rear axle geometry (Prior to build date (RPO) 9435). Your build date is 9055 Corne, so is relevant to your C5.
Checking values
TrackingNon-adjustable0°46’ ± 0°11’
CamberNon-adjustable-1° ± 20'

cornesoutafrica
Posts: 161
Joined: 05 Nov 2018, 19:20
x 9

Re: C5 mk1 wheel alignment

Post by cornesoutafrica »

Thanks Mark.

Now just trying to figure out how to do what to get it to the correct specs. I guess my vastor and camber is out. But how do you adjust the not adjustable?

User avatar
GiveMeABreak
Forum Admin Team
Posts: 20345
Joined: 15 Sep 2015, 19:38
x 2002

Re: C5 mk1 wheel alignment

Post by GiveMeABreak »

The only thing I can suggest is to check the bushes and front lower control arms, bearings etc. for damage or wear Corne.

cornesoutafrica
Posts: 161
Joined: 05 Nov 2018, 19:20
x 9

Re: C5 mk1 wheel alignment

Post by cornesoutafrica »

Well. After 17 years I bet they are tired.

Guess new ones are needed. Any suggestions on which brand to use for the bushes?Doubt I’d get it from Citroën. New parts. Something new to do. I’m excited.

Regards
Corne

Gibbo2286
Donor 2020
Posts: 4533
Joined: 08 Jun 2011, 18:04
x 746

Re: C5 mk1 wheel alignment

Post by Gibbo2286 »

If the handling and steering is ok and there's no unusual tyre wear I'd disregard the settings, the mot tester will find and list any worn bushes/bearings..

cornesoutafrica
Posts: 161
Joined: 05 Nov 2018, 19:20
x 9

Re: C5 mk1 wheel alignment

Post by cornesoutafrica »

In South Africa. We do not have an MOT. You buy a car. Put it through a roadworthy test and as long as it is yours and not in a serious accident you never have to do any roadworthy ever again. So I have to keep a close eye on it and due to the lack of dealerships and likeability for Citroens one must do most things yourself. Your average mechanic does more damage to a Citroen than repair it this side of the world...

Well I don’t have any tyre wear and the steering wheel stays centre and no pulling on the road. Only concern after adjustment today is that when you accelerate I need to turn the wheel slightly anti clockwise. So I guess there is movement. I hit a pothole 2 days ago and lost a tyre. Im wondering if it didnt do more damage than just the tyre....

User avatar
GiveMeABreak
Forum Admin Team
Posts: 20345
Joined: 15 Sep 2015, 19:38
x 2002

Re: C5 mk1 wheel alignment

Post by GiveMeABreak »

A distinct possibility Corne, I forgot about the pothole!

cornesoutafrica
Posts: 161
Joined: 05 Nov 2018, 19:20
x 9

Re: C5 mk1 wheel alignment

Post by cornesoutafrica »

Well. Time to import a passanger side control arm and bushes. Might be worthwhile to also do bushes on drivers side. Although she is a low mileage car, age deteriorate the rubber I believe.

Always something to do. Will import the bits and then dig the thread out again and post pictures and my findings

User avatar
Clogzz
Posts: 2075
Joined: 15 May 2005, 18:04
x 18

Re: C5 mk1 wheel alignment

Post by Clogzz »

when you accelerate I need to turn the wheel slightly anti clockwise
Had that.
Swapping the front wheels around fixed it. :mrgreen:

Gibbo2286
Donor 2020
Posts: 4533
Joined: 08 Jun 2011, 18:04
x 746

Re: C5 mk1 wheel alignment

Post by Gibbo2286 »

Clogzz wrote:
11 Mar 2019, 02:13
when you accelerate I need to turn the wheel slightly anti clockwise
Had that.
Swapping the front wheels around fixed it. :mrgreen:


First you need to be sure that the tyres are not 'directional' i.e. not changeable left to right. mine are on my C5, have arrows on the side to show which way.

User avatar
Paul-R
Donor 2020
Posts: 4035
Joined: 07 May 2009, 16:24
x 399

Re: C5 mk1 wheel alignment

Post by Paul-R »

Try swapping them front to rear.
