Look up please.

Post by Gibbo2286 »

My scan says "Diesel additive system, defect filler cap sensor or additive level error."

I'm assuming it's either the wiring from the filler neck or the sensor at the other end, Anyone know what's the most likely?

There are no DMF warnings popping up on the car and it's running fine.

Also there are plenty of the sensors listed but none seem to have the same part number I found in Service Citroen i.e. 1525.CV, and the harness 6534.NV, I'd like to be sure before I order.
Man is, by nature, a lazy beast, he does not need twice encouraging to do nothing.
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Look up please.

Post by GiveMeABreak »

Assuming this is for your car VIN ending in 202....

6534HY is the Plug Presence Detection Harness (item 25)
6534NV is the Particle Filter Harness (item 26)
Please Don't PM Me For Technical Help

Marc
Gibbo2286
(Donor 2020)
Posts: 7170
Joined: 08 Jun 2011, 18:04
Location: GL15***
My Cars: 2006 C5 2.0 Litre HDI VTR Automatic Estate.(now sold on)
Currently Renault Zoe 2014 ZE
x 2500

Re: Look up please.

Post by Gibbo2286 »

Thanks Marc, any experience of a cure for the fault, harness, sensor, connections?

I might have to put the overalls on again and get under there when I promised myself I wouldn't do any more. :(
Man is, by nature, a lazy beast, he does not need twice encouraging to do nothing.
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Look up please.

Post by GiveMeABreak »

I'd need the full fault codes Gibbo - but most of the similar issues have been down to the plug detect harness needing replacing.
Please Don't PM Me For Technical Help

Marc
Gibbo2286
(Donor 2020)
Posts: 7170
Joined: 08 Jun 2011, 18:04
Location: GL15***
My Cars: 2006 C5 2.0 Litre HDI VTR Automatic Estate.(now sold on)
Currently Renault Zoe 2014 ZE
x 2500

Re: Look up please.

Post by Gibbo2286 »

Thanks Marc, maybe I'll raise the necessary enthusiasm...….soon.
Man is, by nature, a lazy beast, he does not need twice encouraging to do nothing.
Gibbo2286
(Donor 2020)
Posts: 7170
Joined: 08 Jun 2011, 18:04
Location: GL15***
My Cars: 2006 C5 2.0 Litre HDI VTR Automatic Estate.(now sold on)
Currently Renault Zoe 2014 ZE
x 2500

Re: Look up please.

Post by Gibbo2286 »

I just removed the harness, a bit of a pain to get out from its route, looked up the price £80 + for what's hardly more than a meter of cable a plug and the plastic packed sensor on the other end. :(

Anyone know what's actually in that sensor pack?
Man is, by nature, a lazy beast, he does not need twice encouraging to do nothing.
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Look up please.

Post by GiveMeABreak »

Check the magnet(s) haven’t gone AWOL first Gibbo.

See picture here:

viewtopic.php?t=59601#p567667
