Xantia Alarm

This is the Forum for all your Citroen Technical Questions, Problems or Advice.

Moderator: RichardW

Post Reply
allanmc
Posts: 314
Joined: 25 Mar 2006, 12:16
Location: cumbernauld
My Cars:

Xantia Alarm

Post by allanmc »

Hi I have a series 2 Xantia 2.0I automatic 1999 in the past few days the alarm has gone off for no apparent reason in the middle of the day can someone help me please
Allan
Xantia 2.0i SX Auto, 1999
MJM
(Donor 2020)
Posts: 134
Joined: 20 Aug 2008, 12:49
Location: Gloucestershire, UK
My Cars:

Re: Xantia Alarm

Post by MJM »

You can eliminate the interior motion sensors by pressing the button on the L H side of the dash until the led lights up and them lock as usual.
Someone with more knowledge than me will advise further, no doubt.
MJM
1999 Dante red Xantia Exclusive 2,0 petrol. No smelly diesel for me. Now re-homed
2007 Wicked Red C5 Exclusive. Now a smelly diesel automatic for me.
wheeler
Posts: 6847
Joined: 21 Sep 2002, 19:07
Location: United Kingdom
My Cars:
x 717

Re: Xantia Alarm

Post by wheeler »

Do you have access to lexia ? you can go into the memory of the CPH & see the last 15 things that triggered the alarm, chances are its either faulty ultrasonic sensors or a dodgy/loose bonnet switch.
allanmc
Posts: 314
Joined: 25 Mar 2006, 12:16
Location: cumbernauld
My Cars:

Re: Xantia Alarm

Post by allanmc »

I have a Lexia but don't know a lot about it but I will have a look
Thanks
Allan
Xantia 2.0i SX Auto, 1999
User avatar
CitroJim
A very naughty boy
Posts: 49518
Joined: 30 Apr 2005, 23:33
Location: Paggers
My Cars: Bluebell the AX, Polly the C3 Picasso, Pix the Nissan Pixo, Propel the duathlon bike, TCR Pro the road bike and Fuji the TT bike...
x 6156
Contact:

Re: Xantia Alarm

Post by CitroJim »

wheeler wrote:Do you have access to lexia ? you can go into the memory of the CPH & see the last 15 things that triggered the alarm, chances are its either faulty ultrasonic sensors or a dodgy/loose bonnet switch.
Or a dodgy boot switch...

Allan, it's easy. Do an normal diagnosis with the Lexia and choose, I think, "Protection"* from the main diagnostic menu. That'll take you to the CPH.

Don't read or erase any faults before selecting "Last 15 Alarm Operates" from the menu. Selecting that will give you a report of the last 15 alarms and what caused them.

If you erase faults before going here then you'll erase the list...

* Someone correct me if I'm wrong please :)
Jim

Runner, cyclist, time triallist, duathlete, Citroen AX fan and the CCC Citroenian 'From A to Z' Columnist...
allanmc
Posts: 314
Joined: 25 Mar 2006, 12:16
Location: cumbernauld
My Cars:

Re: Xantia Alarm

Post by allanmc »

Thanks Jim, I will give that a try and see how I get on
Regards
Allan
Xantia 2.0i SX Auto, 1999
User avatar
Mandrake
Posts: 8614
Joined: 10 Apr 2005, 17:23
Location: North Lanarkshire, UK
My Cars:
x 664

Re: Xantia Alarm

Post by Mandrake »

CitroJim wrote: Allan, it's easy. Do an normal diagnosis with the Lexia and choose, I think, "Protection"* from the main diagnostic menu. That'll take you to the CPH.

Don't read or erase any faults before selecting "Last 15 Alarm Operates" from the menu. Selecting that will give you a report of the last 15 alarms and what caused them.

If you erase faults before going here then you'll erase the list...

* Someone correct me if I'm wrong please :)
That's correct, if you erase the faults it will also erase the log of alarm activation causes.

It won't let you erase faults until after they have been read, but it doesn't care whether you have read the alarm activations first so you could loose them if you don't check them first.

If it does turn out to be the ultrasonic sensors here is a long detailed thread showing my diagnosis and repair of the ultrasonic sensors on my car:

http://www.frenchcarforum.co.uk/forum/v ... =3&t=41002" onclick="window.open(this.href);return false;

Still working perfectly with zero false alarms over a year later. :)
Simon

1997 Xantia S1 3.0 V6 Auto Exclusive in Silex Grey
2016 Nissan Leaf Tekna 30kWh in White

2011 Peugeot Ion Full Electric in Silver
1977 G Special 1129cc LHD
1978 CX 2400
1997 Xantia S1 2.0i Auto VSX
1998 Xantia S2 3.0 V6 Auto Exclusive
allanmc
Posts: 314
Joined: 25 Mar 2006, 12:16
Location: cumbernauld
My Cars:

Re: Xantia Alarm

Post by allanmc »

Jim, I had a go with the Lexia today switched on and for the first time it asked for the RPO no. plus the Vin no. which I entered didnt ask for the model of car just went straight to 4 options I went to click on faults but clicked the one above which I think was directory did'nt know what to do then so shut it all down and started again but this time it asked for the model of car and only the vin no. went to diagnostics and scrolled to Protection but that just came up with the Air bags gave up at that went back just know and it wouldnt read anything no dialog so as I am going out I have had to give up.Sorry to be so long winded about this hope you can help please
Regards
Allan
Xantia 2.0i SX Auto, 1999
User avatar
CitroJim
A very naughty boy
Posts: 49518
Joined: 30 Apr 2005, 23:33
Location: Paggers
My Cars: Bluebell the AX, Polly the C3 Picasso, Pix the Nissan Pixo, Propel the duathlon bike, TCR Pro the road bike and Fuji the TT bike...
x 6156
Contact:

Re: Xantia Alarm

Post by CitroJim »

If you can wait a bit Allan I'll drag mine out and give guidance on what to do properly.. be a few days mind.

It must be one of the other menus... Simon, can you recall which the CPH is in?
Jim

Runner, cyclist, time triallist, duathlete, Citroen AX fan and the CCC Citroenian 'From A to Z' Columnist...
User avatar
Mandrake
Posts: 8614
Joined: 10 Apr 2005, 17:23
Location: North Lanarkshire, UK
My Cars:
x 664

Re: Xantia Alarm

Post by Mandrake »

Not off the top of my head Jim, without going out in the cold and hooking the Lexia up... :twisted:

Allan, if you can't find it just go into global test instead of test by function, it will take a couple of minutes to scan all the ECU's but the CPH will be near the bottom of the list - you can select it from there.
Simon

1997 Xantia S1 3.0 V6 Auto Exclusive in Silex Grey
2016 Nissan Leaf Tekna 30kWh in White

2011 Peugeot Ion Full Electric in Silver
1977 G Special 1129cc LHD
1978 CX 2400
1997 Xantia S1 2.0i Auto VSX
1998 Xantia S2 3.0 V6 Auto Exclusive
User avatar
Mandrake
Posts: 8614
Joined: 10 Apr 2005, 17:23
Location: North Lanarkshire, UK
My Cars:
x 664

Re: Xantia Alarm

Post by Mandrake »

Security rings a bell...
Simon

1997 Xantia S1 3.0 V6 Auto Exclusive in Silex Grey
2016 Nissan Leaf Tekna 30kWh in White

2011 Peugeot Ion Full Electric in Silver
1977 G Special 1129cc LHD
1978 CX 2400
1997 Xantia S1 2.0i Auto VSX
1998 Xantia S2 3.0 V6 Auto Exclusive
User avatar
CitroJim
A very naughty boy
Posts: 49518
Joined: 30 Apr 2005, 23:33
Location: Paggers
My Cars: Bluebell the AX, Polly the C3 Picasso, Pix the Nissan Pixo, Propel the duathlon bike, TCR Pro the road bike and Fuji the TT bike...
x 6156
Contact:

Re: Xantia Alarm

Post by CitroJim »

Mandrake wrote:Security rings a bell...

So does Quasimodo...
Jim

Runner, cyclist, time triallist, duathlete, Citroen AX fan and the CCC Citroenian 'From A to Z' Columnist...
User avatar
myglaren
Forum Admin Team
Posts: 25361
Joined: 02 Mar 2008, 13:30
Location: Washington
My Cars: Mazda 6
Ooops.
Previously:
2009 Honda Civic :(
C5, C5, Xantia, BX, GS, Visa.
R4, R11TXE, R14, R30TX
x 4888

Re: Xantia Alarm

Post by myglaren »

=D> :mrgreen:
allanmc
Posts: 314
Joined: 25 Mar 2006, 12:16
Location: cumbernauld
My Cars:

Re: Xantia Alarm

Post by allanmc »

Thanks Jim, there is no hurry, whenever you have the time and thanks to everyone else for your suggestions
Allan
Xantia 2.0i SX Auto, 1999
User avatar
Stickyfinger
(Donor 2016)
Posts: 10411
Joined: 28 Mar 2013, 21:05
Location: Somset my lovleee
My Cars: Xantia V6 ACTIVA 3ltr 24v Manual p1
Xm 2.1TD Ph2 Exclusive
AX, little Daffodil
SAXO White Mk1. Sally
x 1280
Contact:

Re: Xantia Alarm

Post by Stickyfinger »

CitroJim wrote:
Mandrake wrote:Security rings a bell...

So does Quasimodo...
agggggggggggggggg
Alasdair
Activa, the Moose Rider
3x C5x7 Steering racks and counting
