I'm trying to fault find and establish what is inside the EGR module on the C5 x7 diesel 2Ltr.
I presumed the actuator on the side moves a valve inside, but with a lot of electrical wires going in...is there another electronic valve inside.
I have a problem where the engine drops in revs in a jumping manner, and it looks like a feedback loop of something between the airdoser valve and the EGR valve or valves.
As the airdoser closes to force air from the EGR into the engine but somehow there is not enough from either making the engine drop in revs after which it goes back and repeats the drop again and again. I heard the phrase kangaroing used.
If anyone has any suggestions why this kangaroing is happening then I'm all ears. When driving it manifests itself as a hesitate of the engine
C5 x7 EGR unit, what's inside ?
Moderator: RichardW
- EDC5
- (Donor 2020)
- Posts: 1216
- Joined: 01 Jul 2017, 21:48
- Location: N. Wales
- My Cars: Citroen C5 RHR AM6
- x 120
Re: C5 x7 EGR unit, what's inside ?
I think there is a stepper motor in the EGR module and perhaps a position senor to relay the actual position back to the ECU.
Whilst I can't recommend blanking the EGR valve off with a simple plate for legal reasons, you could maybe try it as a 'diagnostic aid' to see if the behaviour stops or changes in some way? Then at least you’ll know if you’re in the ballpark.
Does your engine have the 'double doseur' or single?
Whilst I can't recommend blanking the EGR valve off with a simple plate for legal reasons, you could maybe try it as a 'diagnostic aid' to see if the behaviour stops or changes in some way? Then at least you’ll know if you’re in the ballpark.
Does your engine have the 'double doseur' or single?
- moizeau
- Donor 2024
- Posts: 1589
- Joined: 12 Jan 2015, 16:08
- Location: France 36
- My Cars: 91 BX TZD Estate. Dead but loved
407 HDI 136 auto
C4 2l petrol coupé
2010 Dispatch III HDI 90
AND a 1980 Z1000ST
AND a 1983 GPz1100 inj
AND a 1995 Zephyr 1100
AND a 1980 Z650 (my moped) - x 315
Re: C5 x7 EGR unit, what's inside ?
If it's the same as the 1.6hdi it's a stepper / servo motor that operates a mechanical butterfly. You can take them apart and test each 1/2 separately.
Not a great picture but on page 1 you can see the 2 halves, the very black pic is the motor side.
viewtopic.php?t=64723
Not a great picture but on page 1 you can see the 2 halves, the very black pic is the motor side.
viewtopic.php?t=64723
Pete
Notice the BX is still top the list but sadly gone
Notice the BX is still top the list but sadly gone
- KennyW
- Donor 2024
- Posts: 2506
- Joined: 17 Jan 2006, 21:22
- Location: Letham, Fife
- My Cars: Current Citroen's
C5 x7 2010
SWMBO C3 2012
Previous Citroen's
Xantia 2.0 90hp estate
Xantia 1.9 TD estate - x 132
Re: C5 x7 EGR unit, what's inside ?
Her C5 has a single doser.
C5 x7 2.0 HDi 160 hp Estate exclusive, the newbie
Xantia 2.0 Hdi 90hp 1999 only 189,000 and rising!!!!!!! Moved on to a new home
C3 1.4 petrol (SWMBO)
Xantia TD 1.9 Mk 2 Estate LX 1998 model over 210,000 miles now and still rising!!!!!!!!!!!!! now deceased 17/12/2010.
Xantia 2.0 Hdi 90hp 1999 only 189,000 and rising!!!!!!! Moved on to a new home
C3 1.4 petrol (SWMBO)
Xantia TD 1.9 Mk 2 Estate LX 1998 model over 210,000 miles now and still rising!!!!!!!!!!!!! now deceased 17/12/2010.
-
- (Donor 2020)
- Posts: 94
- Joined: 05 Dec 2019, 22:20
- Location: Liverpool
- My Cars: C5 estate 2l diesel 2011
Re: C5 x7 EGR unit, what's inside ?
Hi guys, thanks for the replies, but are you all saying there are two gates or valves the the EGR.
I found a blanc plate on the exit port of the EGR, removed it and my kangaroing has stopped. Probably because it can't choke the engine now the EGR is open.
Oh, Bela is a man's name lol
I found a blanc plate on the exit port of the EGR, removed it and my kangaroing has stopped. Probably because it can't choke the engine now the EGR is open.
Oh, Bela is a man's name lol
- Paul-R
- Donor 2023
- Posts: 6931
- Joined: 07 May 2009, 16:24
- Location: Wirral, NW England; Vaucluse 84, France
- Lexia Available: Yes
- My Cars: 2015 1.6 Blue HDi 120 Peugeot 308 Active SW
2013 2.0 HDi 163 C5 Exclusive Tourer
2003 2.0 HDi 110 C5 Exclusive Estate (Gone)
2001 2.0 HDi 90 Xsara Estate (Gone) - x 1378
Re: C5 x7 EGR unit, what's inside ?
And this was my second thought.
There was a bust of him in front of the hotel we stayed in 2011 in the small town of Jimbolia in Romania. He was born in the nearby town of Sânnicolau Mare.
There was a bust of him in front of the hotel we stayed in 2011 in the small town of Jimbolia in Romania. He was born in the nearby town of Sânnicolau Mare.
