C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter - ???

Post by rmunns »

First, mine is a left hand drive, year 2010. With the car being new-to-me, I bought a set of filters - oil, air, cabin, like a good boy.

Air - fitted OK, no problems.

Cabin - eventually found and retrieved old one (driver's side). To get the old one out I had to practically ruin it - just not enough room, with accelerator (not big prob.) and brake pedal (right in the way). No clutch (automatic). But at least it is very dirty, so I guess the change will be noticeable.
I can't see how I will get the new one in. Any tips, please?

Oil filter. I have not spotted this, despite a good search. Can anyone help, please? Also, any hints?
rmunns
Posts: 611
Joined: 09 Jul 2009, 22:09
Location: Southern Dordogne, France
My Cars: 2019 C5 Aircross 2litre diesel, auto.
2018 C4 Pic2 Spacetourer auto. Seems nice so far.
2019 C4 Cactus manual. Didn't like it, lots of niggling points. sold.
2011 C4 Picasso excl. - shaping up to be a disaster, bought June 2019. P/X'd
2009 Citroen C5 X7 exclusive, auto, LHD, 207500km (129000miles) now sold
Citroen Xsara Picasso excl. 2004 2.0 Hdi, RHD, 64000miles. (sold)
Citroen C3 Picasso excl. 2016. sold.
Two Xantias, one petrol, one diesel. sold.

In the past: Renault 16 (in about 1977, for a year). With front pass. seat out transported full bathroom suite from Cambridge to Derby!)
Renault 4TL (in 2011, for a year)
x 9

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by rmunns »

Anyone please on cabin filter? - I'm stuck!
User avatar
DickieG
Monaco's youngest playboy
Posts: 4877
Joined: 25 Nov 2006, 09:15
Location: Buckinghamshire
My Cars:
x 38

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by DickieG »

rmunns wrote:Anyone please on cabin filter? - I'm stuck!
Place it against the bulkhead and then bend it slightly to get in in place, did mine a few days ago and must be even harder with RHD because the back of the glovebox gets in the way.
13 Ram 1500 Hemi
14 BMW 535D Tourer
19 BMW i3s
06 C3 Desire 1.4
72 DS 21 EFi Pallas BVH
rmunns
Posts: 611
Joined: 09 Jul 2009, 22:09
Location: Southern Dordogne, France
My Cars: 2019 C5 Aircross 2litre diesel, auto.
2018 C4 Pic2 Spacetourer auto. Seems nice so far.
2019 C4 Cactus manual. Didn't like it, lots of niggling points. sold.
2011 C4 Picasso excl. - shaping up to be a disaster, bought June 2019. P/X'd
2009 Citroen C5 X7 exclusive, auto, LHD, 207500km (129000miles) now sold
Citroen Xsara Picasso excl. 2004 2.0 Hdi, RHD, 64000miles. (sold)
Citroen C3 Picasso excl. 2016. sold.
Two Xantias, one petrol, one diesel. sold.

In the past: Renault 16 (in about 1977, for a year). With front pass. seat out transported full bathroom suite from Cambridge to Derby!)
Renault 4TL (in 2011, for a year)
x 9

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by rmunns »

Thanks, I'll try now. If I get stuck again, would you pop in on your way to Monaco?
Estately
(Donor 2022)
Posts: 183
Joined: 02 Nov 2010, 20:50
Location: Stafford
My Cars: 00 Xantia 2.0 HDI 90 bhp Estate 237k Gone to New Home
07 C5 2.0 HDI 138 Exclusive Estate 211k. Gearbox selector failed.
10 C5 2.0 HDI 138 Auto Exclusive Estate. Px'd
13 C5 2.0 HDI 160 Manual Exclusive Tourer.
x 13

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by Estately »

The location of the cabin pollen filter is very poorly thought out if indeed any thought was used. Having replaced mine last night (RHD) and with the benefit of hindsight I might have used some silicon spray or silicon polish on the top and lower edges. It felt as though I was wrecking the the new filter given the bending and twisting to get it in and am still not sure that the far end is fully home.

The C5 II had a 5.5 mm screw to locate the pollen filter cover cover but I'm not sure if the C5 X7 should have or not as there were none present.

Just another point I take it that the air flow through the filter is towards the back of the car, if anyone can put me right on this.

The oil filter on our 136 2.0L Hdi is to the right of the alternator, a black plastic cover and needs a 27mm socket to liberate it, the same size socket is needed for the fuel filter.

Hope that helps

Andy.
If it can happen it will.
rmunns
Posts: 611
Joined: 09 Jul 2009, 22:09
Location: Southern Dordogne, France
My Cars: 2019 C5 Aircross 2litre diesel, auto.
2018 C4 Pic2 Spacetourer auto. Seems nice so far.
2019 C4 Cactus manual. Didn't like it, lots of niggling points. sold.
2011 C4 Picasso excl. - shaping up to be a disaster, bought June 2019. P/X'd
2009 Citroen C5 X7 exclusive, auto, LHD, 207500km (129000miles) now sold
Citroen Xsara Picasso excl. 2004 2.0 Hdi, RHD, 64000miles. (sold)
Citroen C3 Picasso excl. 2016. sold.
Two Xantias, one petrol, one diesel. sold.

In the past: Renault 16 (in about 1977, for a year). With front pass. seat out transported full bathroom suite from Cambridge to Derby!)
Renault 4TL (in 2011, for a year)
x 9

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by rmunns »

Thanks for the info regarding the oil filter location - I'll see if mine is the same..
Cabin filter; yes, the airflow is towards back of car. Mine also has no screw for the cover, although it's clear where it would go, but there are two 'clickers' holding the cover in.

Warning. I got my new cabin filter in, but tried to be too clever and pushed it in too far. Big problem - it 'falls' sideways into the void and is a bu**er to get back into place. I used a 3mm allen key and several choice swearwords.
User avatar
bobins
Donor 2023
Posts: 5697
Joined: 05 Jul 2012, 18:07
Location: Midhurst, West Sussex
My Cars: Kia Sportage
Mazda BT-50
Land Rover SIII SWB
V-F-R800
SL320
MX5
x 2871

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by bobins »

Regarding the pollen filter, Cit Service says: "It will be necessary to play on the flexibility of the filter in order to be able to extract it". In other words - it's a tight fit. :-D
Sadly no longer a C5 owner :(
User avatar
Stickyfinger
(Donor 2016)
Posts: 10411
Joined: 28 Mar 2013, 21:05
Location: Somset my lovleee
My Cars: Xantia V6 ACTIVA 3ltr 24v Manual p1
Xm 2.1TD Ph2 Exclusive
AX, little Daffodil
SAXO White Mk1. Sally
x 1280
Contact:

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by Stickyfinger »

"It will be necessary to play on the flexibility of the filter in order to be able to extract it".

To translate that correctly from the original French it should read

"Oh crap, we had a brain fart, we forgot about it and had throw something in there" !
Alasdair
Activa, the Moose Rider
3x C5x7 Steering racks and counting
MikeT
Posts: 4809
Joined: 11 Jun 2007, 16:17
Location: Christchurch, Dorset. UK
My Cars: 2005 C5restyle 1.6HDI 16v 110hp VTR Estate
2008 C5 X7 1.6HDI VTR+ Saloon
x 231

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by MikeT »

lol, that's the instructions for extraction. The OP is asking how to refit a replacement, which could be even more of a fudge. On mine (RHD) I had to crease the filter to get it fully home - can't imagine having a full set of pedals in the way too! So it seems, the neanderthal method of "just force it" is the only solution.
User avatar
qprdude
Posts: 1754
Joined: 06 Apr 2012, 18:56
Location: Woking, Surrey
My Cars: Renault 5 TS, Renault 14ts, Citroen C5 Mk1, Renault Clio sport, Renault Laguna Privilege. Citroen C5 X7 Exclusive. Citroen DS5 D/sport . And around 25+ other brands from Morris Oxford to S Type jag and most things between.
x 10

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by qprdude »

You think the C5 filter is difficult? You should try a Rover 75. Remove the scuttles from around the bottom of the windscreen Remove the filter face plate and destroy it to get it out. It is placed in a plenum chamber between the engine bay and cabin and is between the bulkhead and the ECU. There is about 20 mm of working space and the new filter has to be bent almost double to fit it. The ECU sits nicely in the plenum chamber, which is famous for the 3 drain tubes getting blocked and "drowning" the ECU. You can hear the water sloshing from side to side when the drains block, but by then it's usually a case of taking the ECU out and drying it. Built at Cowley, designed by madmen and driven by sedate old gentlemen like myself.
Rick.

2013 Citroen DS 5 D/Sport
2007 Renault Clio Campus sport. 1.2l

Sometimes the change doesn't work.
vborovic
Locked user account
Posts: 1750
Joined: 31 Oct 2013, 17:07
Location: Somewhere
My Cars: A used Citroen
x 27

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter -

Post by vborovic »

qprdude wrote:Built at Cowley, designed by madmen and driven by sedate old gentlemen like myself.
User avatar
Sloppysod
Donor 2024
Posts: 965
Joined: 23 May 2015, 23:35
Location: North Wales
My Cars: Citroens
1 x GS, 1 x GSX (Banger raced), 1 x GSA,
2 x CX Famililles, 1 x CX GTI,
BX, XM, Xantia, C5 Mk1,
C4 (Coupe), C4 (B7),
C5 (X7)

Renault
R4 Van
Fuego
Clio Campas
x 212

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter - ???

Post by Sloppysod »

Hi, All,
Just fitted a replacement Pollen filter to my 2011 C5 today and think I may have done something wrong?, the steps I took were.
1, Move seat to rearmost position,
2, Removed foot well finishing panel, goes front left to centre under glove box.
3, Removed the center console lower forward trim.
4, Removed the Facia panel ventilation channel (small 50 mm diameter elbow pipe).
5, Un-clipped the filter retaining plate.
6, Removed the filter, needed to use a screw driver to help.
7, Rolled the new filter so both ends were about touching.
8, Slid the filter in without any problems.
9 Rebuilt the car as per the steps above.

About 6 minutes to do, my first time, on this car, no swearing on moaning, so what did I do wrong?

Oh the hardest part was determining the orientation of the filter, but thanks to the post earlier I had a rough idea.
:-D :-D :-D :-D :-D :rofl2:

Note, I l also added a screw, to just be on the safe side of caution.
Stu 🏴󠁧󠁢󠁷󠁬󠁳󠁿

"Some cause happiness wherever they go, others whenever they go"Oscar Wilde (1854-1900)

Major interventions
C5 Steering rack @ 58,000 mi
4 discs & Pads @ 63,585 mi
2 (AM6) oil exchanges @ 58,876 & 72,378 mi
User avatar
ozzdownunder
Posts: 49
Joined: 26 Apr 2016, 07:25
Location: Sydney NSW Australia
My Cars: Current =C5 X7 Limited Edition 2014 HDI, Turbo 2.2L LT Sedan built 2014. Triumph, Holden Commodore, Range Rovers, Rovers.

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter - ???

Post by ozzdownunder »

Good one, so how did u determine the orientation of the filter ? Also any ideas on where the Aircond water evaporation tubes are located?
User avatar
GiveMeABreak
Forum Admin Team
Posts: 37005
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5646

Re: C5 II (X7) - 2.0 Hdi 160 - cabin filter and oil filter - ???

Post by GiveMeABreak »

I did a full write up with pics here Stu....

viewtopic.php?f=3&t=56902&hilit=pollen+filter
