Strut mounts/top mounts

Post by xantiagreen »

Hi, I was cleaning the car and noticed that from under the front wheel arches the mounts seemed in good shape but realised that all hell could be breaking loose where I cant see in between, now would it be a good idea to un bolt the strut mounts/top mounts and either paint with a good quality anti rust paint and cover it in thick grease and sandwich back together or clean the rust of if any and grease and back together, as I've had heartattack moment once before groaning, squeaking off the kerb and nasty bulge through bonnet.

Thanks in advance.
Faz

90 Ax 1.0 Red
90 Bx 1.7 TZD Green
92 Bx Gti BRG
90 Bx 16v Cream
96 Xantia 2lt 16v Sx Olive green
01 Xantia 110 Hdi
Storm Grey (SOLD 4/11/18)

Temporarily driving Polo 1.9sdi

All I want is a Bx Gti or 16v!
xantiagreen
Posts: 393
Joined: 13 Sep 2013, 04:45
Location: Lancashire
My Cars:
x 2

Re: Strut mounts/top mounts

Post by xantiagreen »

forgot to mention is Tectyl wax spray any good by Valvoline, says it hardens up and cannot be washed off and so on, spray the mounts with this stuff and grease.
Faz

90 Ax 1.0 Red
90 Bx 1.7 TZD Green
92 Bx Gti BRG
90 Bx 16v Cream
96 Xantia 2lt 16v Sx Olive green
01 Xantia 110 Hdi
Storm Grey (SOLD 4/11/18)

Temporarily driving Polo 1.9sdi

All I want is a Bx Gti or 16v!
citronut
Posts: 10937
Joined: 29 Apr 2005, 00:46
Location: United Kingdom east sussex
My Cars:
x 92

Re: Strut mounts/top mounts

Post by citronut »

i belive the problem with applying wax and or grease to the strut tops will cause them to fail quicker,

as the way these are constructed they rely on the bonded rubber over the surface and in between, to hold the two main component parts together,

rustproofing wax's and grease will deteriorate the bonded rubber,
Regards, malcolm.

current ride a BX 1.7 TZD estate
1986 MK1 BX 1.9na D Auto(in Mothman Andy's stable )
layed up roppy 1.9TD XANT estate, now gone to meet her maker
purple and lilac metalic 2CV(VIOLET)registered to her in doors
1972 DS special been layed up aprox 31 years
xantiagreen
Posts: 393
Joined: 13 Sep 2013, 04:45
Location: Lancashire
My Cars:
x 2

Re: Strut mounts/top mounts

Post by xantiagreen »

citronut wrote:i belive the problem with applying wax and or grease to the strut tops will cause them to fail quicker,

as the way these are constructed they rely on the bonded rubber over the surface and in between, to hold the two main component parts together,

rustproofing wax's and grease will deteriorate the bonded rubber,

Ohhh Sugar I've already applied grease by carlube in between the wheel arch and rubber mount and also greased from top and sprayed wax. How do I remove it all.
Faz

90 Ax 1.0 Red
90 Bx 1.7 TZD Green
92 Bx Gti BRG
90 Bx 16v Cream
96 Xantia 2lt 16v Sx Olive green
01 Xantia 110 Hdi
Storm Grey (SOLD 4/11/18)

Temporarily driving Polo 1.9sdi

All I want is a Bx Gti or 16v!
User avatar
myglaren
Forum Admin Team
Posts: 25477
Joined: 02 Mar 2008, 13:30
Location: Washington
My Cars: Mazda 6
Ooops.
Previously:
2009 Honda Civic :(
C5, C5, Xantia, BX, GS, Visa.
R4, R11TXE, R14, R30TX
x 4922

Re: Strut mounts/top mounts

Post by myglaren »

xantiagreen wrote:
Ohhh Sugar I've already applied grease by carlube in between the wheel arch and rubber mount and also greased from top and sprayed wax. How do I remove it all.
User avatar
Stickyfinger
(Donor 2016)
Posts: 10445
Joined: 28 Mar 2013, 21:05
Location: Somset my lovleee
My Cars: Xantia V6 ACTIVA 3ltr 24v Manual p1
Xm 2.1TD Ph2 Exclusive
AX, little Daffodil
SAXO White Mk1. Sally
x 1297
Contact:

Re: Strut mounts/top mounts

Post by Stickyfinger »


TherMite ?
Alasdair
Activa, the Moose Rider
3x C5x7 Steering racks and counting
xantiagreen
Posts: 393
Joined: 13 Sep 2013, 04:45
Location: Lancashire
My Cars:
x 2

Re: Strut mounts/top mounts

Post by xantiagreen »

BT endured years of thermite damage when they had payphones everywhere (apparenlty)

Any hows do the ther-mites eat the grease leaving it nice and clean, some grease, penetrating oil companies say it's ok to use on metal, plastic, wood and rubber.
Faz

90 Ax 1.0 Red
90 Bx 1.7 TZD Green
92 Bx Gti BRG
90 Bx 16v Cream
96 Xantia 2lt 16v Sx Olive green
01 Xantia 110 Hdi
Storm Grey (SOLD 4/11/18)

Temporarily driving Polo 1.9sdi

All I want is a Bx Gti or 16v!
User avatar
Old-Guy
Posts: 1798
Joined: 11 Sep 2008, 12:08
Location: Gloucestershire
My Cars: 2011 Grand C4 Picasso VTR+ 1.6HDi in Kyanos Blue
1995 Xantia Estate SX 1.9TD in Vert Vega "The Green Lady" - now owned by XanTom
1998 Xantia 2.1 VXD Estate in Mauritius Blue - R.I.P. (terminal tin-worm)
x 17

Re: Strut mounts/top mounts

Post by Old-Guy »

Anything petroleum-based will attack the rubber to a greater extent. The usual failure mode in the UK is that the steel mounting flange (under the wheel-arch) rusts out where it's not visible. In part this is because the rubber is porous enough for moisture and air to reach the bare steel under the rubber. If you clean off the wax/grease/oil with hot water and detergent (but soak as little as possible, allow the rubber to dry in a warm place overnight, then paint the mating surfaces of the mount and the wheel-arch with a thin coat of underseal and re-fit the mount while the under seal is still soft. This will stop (salty) water creeping in between. Wash spilt LHM off the rubber with warm soapy water.

In hotter climates, like down-under, the problem is different; the rubber deteriorates in the heat.
2011 Grand C4 Picasso VTR+ 1.6HDi in Kyanos Blue
1995 Xantia Estate SX 1.9TD in Vert Vega "The Green Lady" - after 11 years now owned by XanTom
1998 Xantia 2.1 VXD Estate in Mauritius Blue - R.I.P. (terminal tin-worm)
citronut
Posts: 10937
Joined: 29 Apr 2005, 00:46
Location: United Kingdom east sussex
My Cars:
x 92

Re: Strut mounts/top mounts

Post by citronut »

i personally belive the metal only starts to rust after the bonded rubber coating starts to break down/perish/crack,
this in turn allows the wet to get to the metal, and also wet gets trapped between the metal parts and the rubber
Regards, malcolm.
