Righto, it's an aircon car so there is a condenser flapping about that I can't remove. My understanding is that you can't remove the box alone.
Nosecone off, slam panel off, radiator/hoses out. Harness disconnected. Clutch slave unbolted.
Then do I unhook the alternator, pump and compressor from the drivetrain, pop the driveshafts and angle the driveline out the bottom, gearbox end pointing down?
How much should I be charging in labour, or to put it another way how many chargeable hours are in it from start to finish?
XM 2.5 Clutch Replacement
Moderator: RichardW
-
- Posts: 8061
- Joined: 30 Dec 2004, 23:10
- Location: Somewhere in North Wales, Anglesey
- My Cars: M reg Xm S2 2.1td Auto Exclusive. 269k and rising
L reg XM S1 V6 12v Manual SEi
L 94 XM 2.1 TD auto total resto
2008 Peugeot 207 Sw 1.6 16v hdi. 217k and rising
2010 Peugeot 207 SW 1.6 8v HDi 161k and rising - x 71
Re: XM 2.5 Clutch Replacement
Massive job Im told Addo.. The real two experts are Robert Smart, and Xmexclusive..
May be a better idea to post this also on Club-xm.co.uk too..
Me I refuse to do them.. HOWEVER I have read since that it can be done in situ.. Cant remember who it was though.
Id say... £1000 garage prices .. or 1500 bucks!
May be a better idea to post this also on Club-xm.co.uk too..
Me I refuse to do them.. HOWEVER I have read since that it can be done in situ.. Cant remember who it was though.
Id say... £1000 garage prices .. or 1500 bucks!
Sharing a pug 207 1.6 hdi Sw 16v.
M reg Xm 2.1 td auto exclusive S2 269k and rising
L reg XM V6 12v SEi auto .. Light project
A very sad...
1994 XM 2.1 d auto
M reg Xm 2.1 td auto exclusive S2 269k and rising
L reg XM V6 12v SEi auto .. Light project
A very sad...
1994 XM 2.1 d auto
- DHallworth
- Donor 2023
- Posts: 2387
- Joined: 20 Nov 2005, 17:05
- Location: Glasgow
- My Cars:
- x 125
Re: XM 2.5 Clutch Replacement
The man to ask about clutch replacement on a 2.5 TD XM is Norrie or Noz from the club-xm forum.
I know for a fact that he has completed a clutch change on a 2.5 without removing the engine. Apparently there is enough room to slide the box out of the way but not enough if you want to remove it.
David.
I know for a fact that he has completed a clutch change on a 2.5 without removing the engine. Apparently there is enough room to slide the box out of the way but not enough if you want to remove it.
David.
'98 Xantia Activa V6
'00 XM V6 Exclusive
'09 C5 2.7 HDi Exclusive
‘10 C5 3.0 HDi Exclusive
'12 C6 3.0 HDi Exclusive
'15 C4 BlueHDi Feel
'00 XM V6 Exclusive
'09 C5 2.7 HDi Exclusive
‘10 C5 3.0 HDi Exclusive
'12 C6 3.0 HDi Exclusive
'15 C4 BlueHDi Feel
Re: XM 2.5 Clutch Replacement
Hey Adam? There has to be easier ways to make money in a booming economy than work like that?
You could do better cutting grass or cleaning windows man!
You could do better cutting grass or cleaning windows man!
Citroen C5 1.6 HDI 110bhp Estate 06 plate
French Mistresses gone.
Citroen C5 HDI Mk 1 hatchback
Vel Satis 3.5 v6
ZX 1.9D Est.
ZX 1.9DHatch
Xantia 1.9td est.
Xantia 2.0 hdi Est.
Xantia V6 MK1
Xantia V6 MK 2
French Mistresses gone.
Citroen C5 HDI Mk 1 hatchback
Vel Satis 3.5 v6
ZX 1.9D Est.
ZX 1.9DHatch
Xantia 1.9td est.
Xantia 2.0 hdi Est.
Xantia V6 MK1
Xantia V6 MK 2
-
- Posts: 321
- Joined: 22 Oct 2009, 12:58
- Location: brentwood essex
- My Cars:
- x 3
Re: XM 2.5 Clutch Replacement
some jobs are better left to someone braver or more desperate! I've never done an XM but I did quite a few 2.0l CXs back in the day and you could squeeze the gearbox sideways enough to fish the clutch out. About 5 hours all in on them. The 2.4 and 2.5 was engine out though! 12 hours! Doubt I'l ever get asked now
