Can you estimate the altitude?
Moderator: RichardW
Can you estimate the altitude?
Here is a OBD data log of my xsara picasso. Can anyone estimate the altitude?
Note:
RPM - Engine speed in rev/min
VKPH - Vehicle speed in km/h
MAP - Intake manifold absolute pressure in kPa
Note:
RPM - Engine speed in rev/min
VKPH - Vehicle speed in km/h
MAP - Intake manifold absolute pressure in kPa
2000 ZX 1.4i
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
Re: Can you estimate the altitude?
Half a bar?
That's quite high indeed. 4000m above sea level? (according to some graph on t'internet)
Or is your air filter just blocked
Alex
That's quite high indeed. 4000m above sea level? (according to some graph on t'internet)
Or is your air filter just blocked
Alex
Citroen Xantia Exclusive HDi
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
Re: Can you estimate the altitude?
Yeah, half a bar When engine speed is zero, manifold pressure equals to ambient pressureChlorate wrote:Half a bar?
That's quite high indeed. 4000m above sea level? (according to some graph on t'internet)
Or is your air filter just blocked
Alex
Although the ambient pressure isn't a linear function of altitude, very roughly, every 1000m increase in altitude would results in 10kPa decrease in pressure.
The answer is, about 5000m
The exact altitude is 5250m, find it on the map:
http://nok.it/Z2Xp8
2000 ZX 1.4i
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
Re: Can you estimate the altitude?
Blimy!
I bet that was interesting.
World's highest Xsara Picasso perhaps?
I bet that was interesting.
World's highest Xsara Picasso perhaps?
That and when your throttle is wide open MAP won't be far off ambient.When engine speed is zero, manifold pressure equals to ambient pressure
Citroen Xantia Exclusive HDi
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
Re: Can you estimate the altitude?
Yeah, indeed it was fantastic Not sure if it's world's highest Pic, but it seems a bit hard to find a place higher than that and still approachable by a Xsara PicassoChlorate wrote:Blimy!
I bet that was interesting.
World's highest Xsara Picasso perhaps?
That and when your throttle is wide open MAP won't be far off ambient.When engine speed is zero, manifold pressure equals to ambient pressure
2000 ZX 1.4i
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
Re: Can you estimate the altitude?
Where the data was logged...
2000 ZX 1.4i
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
Re: Can you estimate the altitude?
Very impressed!
Did you have a video camera on that plane?
Did you have a video camera on that plane?
Citroen Xantia Exclusive HDi
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
Re: Can you estimate the altitude?
I had a remote controlled camera with me. However, during the trial flight I found that there wouldn't be sufficient lift for a camera because the air is way too thin, and battery performance was poor at low temp. So I had to give upChlorate wrote:Very impressed!
Did you have a video camera on that plane?
Checking data...
I posted some pictures here:http://www.frenchcarforum.co.uk/forum/v ... 21&t=41986
2000 ZX 1.4i
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
2006 Xsara Picasso 2.0i
2011 C5 2.3i (EW12A)
2003 Xsara Picasso 2.0HDi
1985 2CV6 Special
Re: Can you estimate the altitude?
That's a real shame, thanks for sharing though
Any more extreme Citroening coming up?
Any more extreme Citroening coming up?
Citroen Xantia Exclusive HDi
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
- SaabC5
- Posts: 765
- Joined: 01 Aug 2011, 23:18
- Location: SW London
- My Cars: 09 C5 X7 2.0Hdi Exclusive
- x 1
Re: Can you estimate the altitude?
I'm driving through Peckham next week, does that count?Chlorate wrote:
Any more extreme Citroening coming up?
09 C5 X7 2.0Hdi Exclusive in Perla Nera black (the best colour)
-
- Posts: 1407
- Joined: 13 Apr 2009, 07:24
- Location: West Sussex U.K
- My Cars:
- x 9
Re: Can you estimate the altitude?
Very good you seem to have got the correct answer but I don't see how, my reading of the data is 200mBar when the engine revs are zero. and 200mB is a lot higher than 5000Metres even with a low QNH about 7000 metres higher. This of course is perverse as one would expect the pressure to be highest when the engine is stationary but never the less thats the way it appears. What have I missed?
cachaciero
cachaciero
2006 Toyota Prius T Spirit
2001 2.2 C5 Exclusive SE
1996 XM 2.1 TD Auto VSX
1995 XM 2.1 TD Auto SX died @ 140K
1987 CX 2.5 Gti Turbo II dead
1984 Ford Scorpio
1981 CX 2.4 Pallas Auto
Renault 21
1220 GS Club
Rover P6 2000TC
2001 2.2 C5 Exclusive SE
1996 XM 2.1 TD Auto VSX
1995 XM 2.1 TD Auto SX died @ 140K
1987 CX 2.5 Gti Turbo II dead
1984 Ford Scorpio
1981 CX 2.4 Pallas Auto
Renault 21
1220 GS Club
Rover P6 2000TC
Re: Can you estimate the altitude?
It's not so much what the pressure is when the engine is stationary, but what the highest pressure the MAP sensor has logged. It doesn't matter how fast or slow the engine is going, in a NA engine the manifold pressure will never be higher than ambient...cylinder pressure is another story...
Note the 50mB plateau on the MAP graph to the right hand side, that correlates to engine and vehicle speed being zero for some time.
Note the 50mB plateau on the MAP graph to the right hand side, that correlates to engine and vehicle speed being zero for some time.
Citroen Xantia Exclusive HDi
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
previously:
Citroen ZX Volcane - RIP
Peugeot 106 XN... stolen and destroyed by Kent Police
-
- Posts: 1407
- Joined: 13 Apr 2009, 07:24
- Location: West Sussex U.K
- My Cars:
- x 9
Re: Can you estimate the altitude?
Chlorate wrote:It's not so much what the pressure is when the engine is stationary, but what the highest pressure the MAP sensor has logged. It doesn't matter how fast or slow the engine is going, in a NA engine the manifold pressure will never be higher than ambient...cylinder pressure is another story...
Note the 50mB plateau on the MAP graph to the right hand side, that correlates to engine and vehicle speed being zero for some time.
Ah! got it! the thing I was missing was the extreme RH side of the data
