putting out C5 service light with DIS LEXIA 2

citronut · Unread post by **citronut** » 26 Sep 2008, 19:48

Dickie G can anyone point a novice (first time user) to how to put out a service light on an 02 C5 2.2 TD HDI with my DIS LEXIA 2 ?????????, i could do with it in brail, triplicate and for the hard of hearing HE HE HE

regards malcolm

DickieG · Unread post by **DickieG** » 26 Sep 2008, 20:11

Hi Malcolm,

Unfortunately I'm not very familiar with C5's yet, I'm going older rather than newer on the car front, ask me a question on a DS and I'll have more idea

When you say service light, I take it the service indicator is not the spanner sign thingy next to the total mileage at the bottom of the speedo? If its one of those then hold down the mileage trip button whilst you turn the ignition on and it will count down for ten seconds and reset. Beyond that I'm in the dark as I haven't got a C5 to plug my Lexia into, has anyone got a C5 to plug my Lxia into to find out? Free diagnostic session

Its a pity the Lexia doesn't cover the EFi system on my DS, I'd like to check that its working 100%.

den169 · Unread post by **den169** » 26 Sep 2008, 20:20

Try this it worked on mine.

With ignition switched OFF

Press & hold the trip reset button ( one you use to 0 the trip mileage )

Turn ignition to ON

Keep the button held down & watch the countdown in the display 9, 8, 7 etc till it gets to 0

When it gets to 0 release the button & it should be reset.
mines an 03 c5 estate

citronut · Unread post by **citronut** » 27 Sep 2008, 08:50

OK thanks Dickie G
i would prefer to go older to, well at least on the car front, but alass i dont get enough oldy's or should that be (ol D's ) to pay my way, i have been trying to find were to plug the DI'LEXIA in on a dersh maybe the N/S head lamp plug TEA HE,

and thanks Den
i will give that a go

regards malcolm

Unread post by **CitroJim** » 27 Sep 2008, 09:08

I have just found a picture of the Lexia for DS diagnostics:

Unread post by **myglaren** » 27 Sep 2008, 10:07

The service sign could be on for a variety of reasons - mine comes on when the screenwash reservoir is low on fluid, goes off when it is filled.

citronut · Unread post by **citronut** » 27 Sep 2008, 16:04

aaah so could it also be on with an air bag fault then,

and yes Den
that dose reset the service spanner but not the luminated service on the right hand instrument

regards malcolm
