Daytime running lights

This is the Forum for all your Citroen Technical Questions, Problems or Advice.

Moderator: RichardW

Post Reply
RichardW
Forum Treasurer
Posts: 10812
Joined: 07 Aug 2002, 17:12
Location: United Kingdom
My Cars: MK2 '17 C4GP 1.6 BlueHDi 120
'13 3008 1.6 HDi GripControl
x 983

Re: Daytime running lights

Post by RichardW »

Original bulbs are 24W, which gives a resistance of 6ohm (R=V²/P). LEDs looks to be 7.5W (you can get them on e-bay), which gives a resistance of 19.2 ohm. Parallel resistances sum by the inverse (ie 1/R1 +1/R2 = 1/Rtot) so applying this for the LED to get the total gives a resistor of 8.7 ohm. On 12V this gives a resistor power of 16.5W
Richard W
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Daytime running lights

Post by GiveMeABreak »

We've moved onto the Angular lighting - these are the HP19W Angular bulbs in the X7 equipped with the Xenon headlamp unit Richard (the non-xenon angular lights take an H7) and these HP19Ws are 19 Watts, not the HP24W DRL which are 24 Watts. I've already done the DRLs and the specific LEDs I used don't need additional load resistors, but the angular lighting replacements indicate otherwise on at least 2 types of LEDs that have been fitted by others - so would appear to need external resistors, otherwise they flash on and off. It is sometimes hard to tell what resistance is already built into some of the CANBUS LEDs as not all suppliers list this information. This example I think clarifies this where no additional resistance is needed with one LED type on the original 24W DRL bulb fitment wiring circuit, yet other LEDs do need additional resistors on the 19W bulb fitment wiring circuit.
Please Don't PM Me For Technical Help

Marc
User avatar
Paul-R
Donor 2023
Posts: 6916
Joined: 07 May 2009, 16:24
Location: Wirral, NW England; Vaucluse 84, France
Lexia Available: Yes
My Cars: 2015 1.6 Blue HDi 120 Peugeot 308 Active SW
2013 2.0 HDi 163 C5 Exclusive Tourer
2003 2.0 HDi 110 C5 Exclusive Estate (Gone)
2001 2.0 HDi 90 Xsara Estate (Gone)
x 1369

Re: Daytime running lights

Post by Paul-R »

RichardW wrote:Original bulbs are 24W, which gives a resistance of 6ohm (R=V²/P). LEDs looks to be 7.5W (you can get them on e-bay), which gives a resistance of 19.2 ohm. Parallel resistances sum by the inverse (ie 1/R1 +1/R2 = 1/Rtot) so applying this for the LED to get the total gives a resistor of 8.7 ohm. On 12V this gives a resistor power of 16.5W
Accepting that the discussion is for a different bulb now, you can easily see what wattage a shunt resistor must dissipate by subtracting one bulb from the other. So any shunt resistor has to have at least that capacity.

My thoughts are that maybe the resistance needed is not as linearly straight forward as you have worked out and that, say, a 24 ohm resistor will provide enough shunt current to fool the BSI. At 12v this will shunt half an Amp and therefore dissipate 6w meaning a 10W resistor would be needed. Experimentation may be the only way to find out for sure but it seems ridiculous to me to have to waste power in this way.
As I get older I think a lot about the hereafter - I go into a room and then wonder what I'm here after.

Inside every old person is a young person wondering what the hell happened.

"Trying is the first step towards failure" ~ Homer J Simpson​
User avatar
Paul-R
Donor 2023
Posts: 6916
Joined: 07 May 2009, 16:24
Location: Wirral, NW England; Vaucluse 84, France
Lexia Available: Yes
My Cars: 2015 1.6 Blue HDi 120 Peugeot 308 Active SW
2013 2.0 HDi 163 C5 Exclusive Tourer
2003 2.0 HDi 110 C5 Exclusive Estate (Gone)
2001 2.0 HDi 90 Xsara Estate (Gone)
x 1369

Re: Daytime running lights

Post by Paul-R »

Alternatively, is the flashing of the LEDs a characteristic of the LED itself? Has anyone tried putting capacitors across the LED to shunt any possible oscillation away? These would not consume power in the same way as a resistor and be a much more satisfactory answer if proven to work.
As I get older I think a lot about the hereafter - I go into a room and then wonder what I'm here after.

Inside every old person is a young person wondering what the hell happened.

"Trying is the first step towards failure" ~ Homer J Simpson​
User avatar
Paul-R
Donor 2023
Posts: 6916
Joined: 07 May 2009, 16:24
Location: Wirral, NW England; Vaucluse 84, France
Lexia Available: Yes
My Cars: 2015 1.6 Blue HDi 120 Peugeot 308 Active SW
2013 2.0 HDi 163 C5 Exclusive Tourer
2003 2.0 HDi 110 C5 Exclusive Estate (Gone)
2001 2.0 HDi 90 Xsara Estate (Gone)
x 1369

Re: Daytime running lights

Post by Paul-R »

And another thought!

Has anyone run a multimeter across the cables feeding an LED when it's flashing? Does the voltage drop in and out - which would imply that the BSI really is causing the flashing - or not?
As I get older I think a lot about the hereafter - I go into a room and then wonder what I'm here after.

Inside every old person is a young person wondering what the hell happened.

"Trying is the first step towards failure" ~ Homer J Simpson​
User avatar
myglaren
Forum Admin Team
Posts: 25362
Joined: 02 Mar 2008, 13:30
Location: Washington
My Cars: Mazda 6
Ooops.
Previously:
2009 Honda Civic :(
C5, C5, Xantia, BX, GS, Visa.
R4, R11TXE, R14, R30TX
x 4888

Re: Daytime running lights

Post by myglaren »

Paul-R wrote: Experimentation may be the only way to find out for sure but it seems ridiculous to me to have to waste power in this way.
Agreed - it seems ludicrous to use low- consumption LEDs than have to waste power and money with shunt resistors - that probably cost more than the LEDs too.
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Daytime running lights

Post by GiveMeABreak »

I'm still deliberating - still not happy with any I have seen so far - but may take the plunge as soon as this flaming rain stops.
Please Don't PM Me For Technical Help

Marc
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Daytime running lights

Post by GiveMeABreak »

So using my calculations for a 19W Original, this would give 7.58 Ohms and 1.58 Amps. Using the same 7.5 LED, this would give a total of 12.52 Ohms and 11.50 Watts.

The problem is, as I think I mentioned earlier somewhere is that there is the power that they give for the LEDs can sometimes vary - as in this example, I managed to track down further specs of these '7.5W' LEDs. The LED Quantity is 5 Pieces (5 x 1.5W = 7.5W), but the power consumption is stated as 2.38W.

So using that as the power figure for the '7.5W LED' would give 60.50 Ohms and a Current of 0.20 Amps, giving a total of 8.66 Ohms and 16.62 Watts .. or have I lost the plot completely now? :shock:
Please Don't PM Me For Technical Help

Marc
User avatar
xf1ref
Posts: 206
Joined: 20 Feb 2012, 05:42
Location: Romania
My Cars: C5 2.0 HDI 163hp
x 10

Re: Daytime running lights

Post by xf1ref »

First I tried the LEDs without resistors but was making just one flash and not repetitive flashes. No error found with diagbox :?
The only way is to try different resistor values for same power in order to have consumption as low as possible...for example 10ohm, 15ohm etc until the Led start to flash. The easiest way is to have a variable resistor to do tests.
Also from what I know the resistance of the filament when is glowing is different compared when the bulb is not powered...but I think we don't need to complicate this.
User avatar
Paul-R
Donor 2023
Posts: 6916
Joined: 07 May 2009, 16:24
Location: Wirral, NW England; Vaucluse 84, France
Lexia Available: Yes
My Cars: 2015 1.6 Blue HDi 120 Peugeot 308 Active SW
2013 2.0 HDi 163 C5 Exclusive Tourer
2003 2.0 HDi 110 C5 Exclusive Estate (Gone)
2001 2.0 HDi 90 Xsara Estate (Gone)
x 1369

Re: Daytime running lights

Post by Paul-R »

Marc - some simple figures.

The 19w original bulb will use ~1.58A at 12v as you worked out. But there is an easier way.

In order to use the same current with a nominal 7.5w LED you would have to sink 19W - 7.5W = 12.5W of power through a bypass resistor. This is near enough to 1A as to make no difference. Therefore the resistor should have a value of 12/1 Ohms i.e. 12 Ohms and have a power dissipation capacity of at least 12W.

There are a few provisos here though. First of all if the LED actually consumes much less power (2.38W) than stated then the bypass resistor will have to have a lower value and higher power rating. Going through the figures:

19W - 2.38W = 16.62W power must be shunted and this will flow 16.62/12 Amps = 1.39A. This will need a resistance of 12/1.39 Ohms = 8.63 Ohms.

Frankly this is all theoretical and as xf1ref says I would just wire a few different values in to see what happens. I would always start off high as these will be cheaper and not have to dissipate so much power. For starters I would match the nominal value of the LED bulb - i.e. a 12 Ohm 7.5W resistor.

In fact there's a handy resistor of just such a value hanging around - the other LED! What happens if you temporarily put two LEDs in parallel? This may not be entirely valid but it would be a starting point.

I still have some questions that need answering first as I posted above.

is the flashing of the LEDs a characteristic of the LED itself?
Has anyone tried putting capacitors across the LED to shunt any possible oscillation away?
Has anyone run a multimeter across the cables feeding an LED when it's flashing?
Does the voltage drop in and out - which would imply that the BSI really is causing the flashing - or not?
As I get older I think a lot about the hereafter - I go into a room and then wonder what I'm here after.

Inside every old person is a young person wondering what the hell happened.

"Trying is the first step towards failure" ~ Homer J Simpson​
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Daytime running lights

Post by GiveMeABreak »

Thanks Paul - I'm out in the car now taking out the DRLs at present (not the HP19s) as I need to make a further modification to the LED.

Regarding these flipping resistors:

Lets assume I am going for an LED that is a 50W (that has 10 x 5W Cree LEDS) - the actual power consumption for this bulb is 3.24W. So doing all the calcs, this will need a resistance of 9.14 Ohms - so a 10 Ohm will be the nearest I can probably get. However these are available in 20W (10 Ohm) or 50W (10 Ohm). From what I have picked up it is recommended to get the 50 Watt resistors as these babies are seriously hot after only a few seconds of operation! This was from some guy who fitted the 20 Watt one initially using this specification of LED for his HP19W replacement.

Thankfully, these are only for the angular bend lighting, so won't be on for very long. But as our friend in Romania, xf1ref says in a previous post, these resistors will likely need to be mounted outside of the bulb housing due to the heat involved.

It's tighter than a crab's rear with the Xenon lamp unit housing with all the tubing for the washer jets and cabling, so I'm going to have another look once I've done this DRL Mod to see where I could mount the HP19W Resistors.

This is such fun!
Please Don't PM Me For Technical Help

Marc
User avatar
Paul-R
Donor 2023
Posts: 6916
Joined: 07 May 2009, 16:24
Location: Wirral, NW England; Vaucluse 84, France
Lexia Available: Yes
My Cars: 2015 1.6 Blue HDi 120 Peugeot 308 Active SW
2013 2.0 HDi 163 C5 Exclusive Tourer
2003 2.0 HDi 110 C5 Exclusive Estate (Gone)
2001 2.0 HDi 90 Xsara Estate (Gone)
x 1369

Re: Daytime running lights

Post by Paul-R »

I'm supposed to be working on my own car so I'll look at the bulk of your post later but there's one thing that stands out.
GiveMeABreak wrote:Lets assume I am going for an LED that is a 50W (that has 10 x 5W Cree LEDS) - the actual power consumption for this bulb is 3.24W.
That doesn't actually make sense unless they mean that each LED is equivalent to an ordinary 5W bulb. That would kind of make sense if the actual power consumption is a tenth, or less, than a halogen incandescent bulb. A halogen bulb is already a bit more efficient, about 10%, than an ordinary incandescent bulb of course.
As I get older I think a lot about the hereafter - I go into a room and then wonder what I'm here after.

Inside every old person is a young person wondering what the hell happened.

"Trying is the first step towards failure" ~ Homer J Simpson​
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Daytime running lights

Post by GiveMeABreak »

That's what they must mean as most of them state these Wattages for each LED. Anyway - I'm not in a good mood, as the flaming LED popped it's socket after the MOD when trying to replace it into the DRL Lens socket under the headlamp. It is now probably floating somewhere in the bumper bay! After all that work. Back to the web to order some new ones now... :twisted:
Please Don't PM Me For Technical Help

Marc
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Daytime running lights

Post by GiveMeABreak »

Right stress over. I should of followed my own advice and padded out the space under the headlamp with a towel to prevent the bulb dropping into the ether if it comes out the holder :roll:

So now these were the original replacement LEDs that I had. I should of realised when I first installed these that for the X7 DRL, the replacement LED does not need a projection lens as that is effectively focussing the top LED into the sky as these DRLs lean out at an angle of about 20 - 30° when mounted in the housing. It is therefore better to remove the top lens (I used a Dremel with a cutting wheel) and then once the fish eye has been levelled, I carefully ground out the plastic a mm or so using a grinding stone. Then I got a needle type screwdriver bit and picked out the remaining glue and lens material. This will now allow the top LED light to be diffused about the cavity and provide a bit more light as you can see in the second and third pictures. These had a claimed 580 Lumens per bulb.
Old 7.5W DRL Plasma Cree
Old 7.5W DRL Plasma Cree
LED Dispersal With Top Lens
LED Dispersal With Top Lens
LED Dispersal Without Top Lens
LED Dispersal Without Top Lens

Now that I managed to drop one of the LEDs into the Bumper area, I've decided to try a newer LED, picture below:
New XB-D Cree
New XB-D Cree
These new ones have a claimed 850 lumens per bulb. :shock: 8-)

Roll on delivery date and this time I must remember to shove a towel down the headlamp recess!
Please Don't PM Me For Technical Help

Marc
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: Daytime running lights

Post by GiveMeABreak »

xf1ref wrote:I think this led's are the brightest version but I don't know how long they will survive. When I tested the resistor I noticed that is becoming very hot after aprox. 1 minute but for cornering light this is ok because the running time is generally small. Just in case, with the resistor glued on cover I do not recommend to stay with the cornering light on more than 1 minute.
OK, I've replaced the HP24Ws again today with the new Cree XBD LEDs that arrived this morning and managed to keep all my skin :-D . I used the dremel to remove the plastic projector lenses - although these were freely rotating so made it a lot more difficult to do.

While I was there I looked again at the Angular HP19W bulbs. Now I can get the cap off ok with a flat bladed screwdriver - but I cannot seem to move / pull / twist the bulb holder at all! How do you get this thing off and out? As usual, Citroen service has all the procedures for every other bulb in the headlamp except this one! No diagram no nothing - not even mentioned. Is this supposed to be twisted off or pulled off as the wire does not seem to have a plug - it looks moulded into one and I cannot move any of it - it looks stuck solid!
Please Don't PM Me For Technical Help

Marc
Post Reply
